Control Valves

PROCESS CONTROL SOLUTIONS

TWO WAY GLOBE CONTROL VALVE

  • Size: 1/2’’ thru 20’’ (DN 15 to DN 500).
  • Body Rating: ANSI 150# thru 2500#.
  • Leakage Class: Class IV, V & VI.
  • Comes with multi spring actuator.
  • No Gland Pushers.
  • Contour/ Skirted and Cage type Plugs.
  • Internal and external spares are common for sizes ½” thru 3”, 4” thru 6” & 8” thru 10” resulting in less inventory.

LINED GLOBE CONTROL VALVE

  • PFA Lined valves.
  • Size: 1’’ thru 8’’ (DN 25 to DN 200).
  • Body Rating: ANSI 150#.
  • Leakage Class: Class VI (Soft seated).
  • Flow Characteristic: Equal percentage.
  • Temperature range: -60°C to +200°c.
  • Comes with multispring actuator.
  • Smallest travel length.
  • Bellow sealed bonnets available.

3 WAY VALVE

  • Flow Diverting and Flow mixing 3 way Globe valves..
  • Line Sizes: ½” thru 12” (15NB thru 300NB).
  • Body rating upto 300#.
  • Temperature: -190 thru +590 degC.
  • Application: Thermic Fluid, Steam, Organic Liquid, Glycol, Contaminated Water etc.

SPECIAL GLOBE VALVES

  • Bellow Sealed Globe Valves.
  • Body MoC: CS, SS, Duplex, Super Duplex, Monel, Inconel, Hastelloy and Higher alloys.
  • SS valves with SS Actuators available for special applications.
  • TC end connection from 1” thru 2” available for Hygenic applications.
  • Micro flow control valves with SS body available for Dosing application.

FLUSH BOTTOM VALVE

  • Valve Size: 1” thru 8” (DN 25 thru DN 200).
  • Pressure Rating: upto 600# .
  • Plug Options: Contour with OPENING into the vessel or within the valve body.
  • Flow Characteristics: ON – OFF.
  • Leakage Class: Class IV & V (Metal to metal seated) & Class VI (soft seated) as per FCI 70-2s.

ON/OFF BALL VALVE

  • Standard or PFA Lined Ball Valve.
  • Valve Size: ½” thru 24” upto 300#.
  • PFA Lined Valve Size: ½” thru 8” 150#.
  • Leakage Class: VI (Soft Seated).
  • Flow Characteristics: ON-OFF/ Throttiling.
  • Temperature Range: -30°C to 180°C.
  • Available with Pneumatic, Electric or Hydraulic actuators.

ACTUATED BUTTERFLY VALVES

  • Valve Size: 2” thru 24” 150#.
  • Standard as well as PFA Actuated Butterfly Valves.
  • Leakage Class’: VI (Soft Seated).
  • Flow Characteristics: Throttling, ON‐OFF.
  • End Connection: Wafer Type.
  • Electric, Pneumatic or Hydraulic actuators available.

TECNIK ELECTRO PNEUMATIC POSITIONER

  • Model: 1030 L & R
  • Linear and Rotary variants available
  • Equivalent to YTC
  • Weather Proof and Flame Proof versions available
  • Can supply with mounting brackets and Link rods
  • Non Smart Positioners
  • Low hysteresis due to lip seal instead of O-rings
  • Internal parts are Hard Anodized

TECNIK ROTARY ACTUATORS

  • Make: Tecnik
  • Confirms to the latest International Standards: IS0 5211, DIN 3337, VD/VDE 3845 & NAMUR
  • Pistons and end caps are made from diecasting aluminum which has high intensity and  light weight
  • Solenoid valves can be easily mounted without connecting plank
  • Multi-travel rotations (e.g. 120° 135° 180°) and three position actuators are also  available on request
